| List of Spare Parts |
| Part No. |
Part Name |
| 0S1571 |
SCREW,CAP,HEXAGON TUBE ASSEMBLY TO TURBOCHARGER AND ELBOW mounting |
| 5M2894 |
WASHER BRACKET TO TEE, BRACKET TO BLOCK, TUBE AS. TO TEE, TUBE AS. to oil cooler |
| 5N2613 |
FLANGE |
| 3P6061 |
GASKET-PUMP FLG TO PLATE TO PUMP |
| 3B8453 |
SEAL-O-RING |
| 1T0132 |
SEAL-O-RING (234.54MM ID) |
| 7E9781 |
PUMP GROUP-AUXILIARY FRESH WATER |
| 9S8752 |
NUT-FULL (3/8-16-THD)(FOR USE WITH STANDARD FILTERS) |
| 0S1588 |
BOLT,MACHINE HOSE ASSEMBLY MOUNTING,HOSE ASSEMBLY TO TRANSMISSION,AND to torque converter |
| 5N2612 |
FLANGE-INLET |
| 4F7387 |
SEAL TUBE ASSEMBLY TO FLANGE |
| 0S1594 |
BOLT (1 IN. LONG 3/8 IN. DIA.) PLATE ASSEMBLY TO SUPPORT ASSEMBLY |
| 5N1939 |
COVER - TO PUMP HOUSING |
| 5N1940 |
GASKET - GASKET TO PUMP HOUSING |
| 5N0408 |
PLATE-ORIFICE (DIA 37) |
| 1T0765 |
BOLT 2.54 cm (1" long) |
|
CHANGE FROM PREVIOUS TYPE |
|
REMFG PART MAY BE AVAILABLE |
|
SEPARATE ILLUSTRATION |
![[2352350-MOUNTING GROUP-RADIATOR ]](https://crm.partsconexion.co/storage/Catalogue/Caterpillar/462/987/part_1462987.gif)
