-1013862 DRIVE GROUP-ACCESSORY
| -1013862 DRIVE GROUP-ACCESSORY | ||
|---|---|---|
![[-1013862 DRIVE GROUP-ACCESSORY ]](https://crm.partsconexion.co/storage/Catalogue/Caterpillar/271/961/part_2271961.gif)
|
||
| Brand | Caterpillar | |
| Model | C280-6 | |
| Part Number | ||
| Description | ||
| List of Spare Parts | ||
| Part No. | Part Name | |
| CHANGE FROM PREVIOUS TYPE | ||
| SEPARATE ILLUSTRATION | ||
| 1013866 | PLATE | |
| 0S1594 | BOLT (1 IN. LONG 3/8 IN. DIA.) PLATE ASSEMBLY TO SUPPORT ASSEMBLY | |
| 0S1585 | BOLT 12.7 MM (1/2") DIAMETER X 38.1 MM (1 1/2") LENGTH GENERATOR to engine | |
| 7E4366 | GEAR (43-TEETH) | |
| 0S1587 | BOLT-BRACKET ASSEMBLY TO TIMING GEAR | |
| 6V7702 | SEAL-O-RING (317.24MM ID) | |
| 8T1812 | BOLT (3/4-10X3.5-IN) | |
| 7W0896 | WASHER (20.5 X 48.0 X 15MM THK) | |
| 2089651 | DRIVE GROUP-ACCESSORY | |
| CHANGE FROM PREVIOUS TYPE | ||
| SEPARATE ILLUSTRATION | ||
