| List of Spare Parts |
| Part No. |
Part Name |
| 9S8748 |
NUT 5T7454 PLATE TO 7T5628 CABLE AS |
| 2W9315 |
WASHER-SPRING |
| 5P8210 |
SEAL-O-RING (31.34MM ID) |
| 4W0924 |
RETAINER |
| 7W2826 |
SPRING |
| 4P7275 |
COVER |
| 1066493 |
WASHER |
| 7N9062 |
HOUSING |
| 8N5763 |
SEAL |
| 8N5764 |
PISTON |
| 8F4610 |
RING-RETAINING |
| 2A5546 |
BOLT,MACHINE GOVERNOR LINKAGE BRACKET |
| 5P0537 |
WASHER 5T7454 PLATE TO 7T5628 CABLE AS |
| 5P6945 |
BOLT (1/4-20X1.125-IN) |
| 4P7274 |
COVER |
| 2W9316 |
VALVE AS (FUEL CONTROL) |
| 9Y8088 |
VALVE-INTERNAL (OIL CONTROL) |
| 8N5765 |
SPRING (35.57MM) |
| 7N9035 |
RETAINER |
| 7W2015 |
EXTENSION ( BULB ) |
| 7W2828 |
SPRING (24.45MM) |
| 9N1754 |
SPRING (4.57MM) |
| 6I1564 |
DIAPHRAGM |
| 3E6760 |
SEAL-O-RING |
| 1153358 |
WASHER (12.7X6.65X0.79-MM THK) |
|
CHANGE FROM PREVIOUS TYPE |
![[9Y8087-CONTROL GROUP-FUEL RATIO ]](https://crm.partsconexion.co/storage/Catalogue/Caterpillar/403/770/part_2403770.gif)
