2346613-SWITCH GROUP-POSITION -HYDRAULIC LOCKOUT

2346613-SWITCH GROUP-POSITION -HYDRAULIC LOCKOUT

Brand	Caterpillar
Model	345C
Part Number	2346613
Description

List of Spare Parts
Part No.	Part Name
2R0524	CONE (BEARING)
2R0525	CUP (ROLLER BEARING)
4I7576	WASHER (66.3X104X3-MM THK)
7M8485	SEAL,ADAPTER,MOTOR PART OF KIT P/N 5R1429
7Y0661	SHAFT (PLANETARY)
7Y0662	SHAFT (PLANETARY)
1994583	BEARING AS
7Y0808	SHIM (1.6mm THICK)
7Y1469	COUPLING
7Y1470	GEAR (SUN) (21 TEETH)
7Y1472	SHIM (0.15mm THICK)
7Y1473	SHIM (0.30mm THICK)
7Y1474	SHIM (0.40mm THICK)
7Y1475	SHIM (0.50mm THICK)
7Y1476	SHIM (0.60mm THICK)
7Y1477	SHIM (0.70mm THICK)
7Y1478	SHIM (0.80mm THICK)
7Y1479	SHIM (1.0mm THICK) (1.00MM THICK)
7Y1480	SHIM (1.6mm THICK) (1.60MM THICK)
7Y1482	CARRIER (PLANETARY)
7Y1483	GEAR (RING) (63 TEETH)
7Y1485	CARRIER (PLANETARY)
7Y1487	GEAR (RING) (85 TEETH)
7Y1488	CARRIER AS
7Y0656	SHAFT (PLANETARY)
7Y1491	GEAR (SUN) (21 TEETH)
7Y1493	SPACER (8.7X50X14-MM THK)
7Y1495	GEAR-PLANETARY (29-TEETH)
7Y1498	COVER
7Y1499	GEAR-PLANETARY (20-TEETH)
7Y1504	GEAR-PLANETARY (20-TEETH)
7Y5235	BOLT (M24X3X190-MM)
1107217	RING (RETAINING)
1141541	PIN (DOWEL)
1695559	GEAR-SUN (26-TEETH)
1994719	GEAR-COUPLING
2003489	HOUSING-MOTOR
2003490	HOUSING-GEAR
2059025	SEAL GROUP-DUO-CONE
2059024	RING-TORIC
2276048	WASHER (26X40X4-MM THK)
0940584	WASHER (40.3X72X1-MM THK)
1994582	BEARING AS
0950891	PIN - SPRING
0963216	SETSCREW-SOCKET (M12X1.75X12-MM)
3E2338	PLUG-PIPE
6V8133	BOLT (M24X3.0X80MM)
7Y1484	SPACER (191X221X8.5-MM THK)
7Y1492	SPACER (67X101.1X10-MM THK)
8C5240	SEAL-O-RING
8T3957	BOLT (SOCKET HEAD) (M12X1.75X30MM)
8T4167	WASHER-HARD (26X44X4-MM THK)
8T4240	RING - RETAINING
1U8846	SEALANT (FOR LOCATIONS A)
	USE AS REQUIRED
	NOT SHOWN
	METRIC PART
