2321569-LINES GROUP-BUCKET CYLINDER -2ND AUXILIARY, LONG STICK

2321569-LINES GROUP-BUCKET CYLINDER -2ND AUXILIARY, LONG STICK

Brand	Caterpillar
Model	301.8
Part Number	2321569
Description

List of Spare Parts
Part No.	Part Name
9R5948	BLOCK
1488867	LEVER ASSEM.
1528181	FITTING AS (QUICK DISCONNECT, MALE)
2045098	FITTING AS (QUICK DISCONNECT, FEMALE)
2308786	HOSE AS
2308787	HOSE AS
2323146	BRACKET
2426994	HOSE AS
2426995	HOSE AS
0897702	BULKHEAD ADAPTOR
1388454	SCREW-TRUSS HEAD (M4X0.7X10-MM)
1488325	CONNECTOR AS.
	(EACH INCLUDES)
3J1907	SEAL VALVE ASSEMBLY TO SEAL- TUBE ASSEMBLY TO LOGIC VALVE
4J5477	SEAL - O - RING (11.23MM OD)
6V8641	CONNECTOR-SEAL (TO LOADER VALVE)
1488336	ADAPTER (STRAIGHT) (-6 ORB X -6 ORFS)
6V8397	SEAL (LATER MACHINES AND FIELD INSTALLED)
6V8636	ADAPTER (SEAL) (ORFS 11/16- 16; PORT 9/16-18)
1488433	TEE AS-ORFS (1 1/16-12 THD)
6V9836	TEE-ORFS SWIVEL
1503036	ELBOW AS.
8T1905	ELBOW-90 DEGREE (FOR 9.52MM OD TUBE)
1565726	VALVE-SHUTOFF (HYDRAULIC LOCKOUT)
1611702	TEE AS
8T2556	TEE-FACE SEAL
2141446	CAP-DUST (HYDRAULIC OIL)
2141447	CAP-DUST (FUEL)
3T0852	LOCKNUT (M8X1.25-THD)
6V3582	CLAMP-HOSE
6V9168	NUT (11/16-16 THD)
8T4189	BOLT (20mm LONG) 0 degrees) (L=20mm) {FOR 5BR, 6CR}
8T4224	WASHER-TO ASSEMBLE VALVE AS AND PLATES
9M8406	CLIP-TO 8X7433 HARNESS AS ON FORE-AFT
9X8250	CLIP

	AVAILABLE REPAIR KIT(S):
1129861	SEAL KIT (INCLUDES SEALS, THRUST RING, STEM AND CONNECTORS)
	(INCLUDES 2 SEALS, 2 CONNECTOR O-RINGS, THRUST RING AND STEM O-RING)
	REFER TO HYDRAULIC INFORMATION SYSTEM
	KIT MARKED J AVAILABLE FOR PART(S) MARKED J
	METRIC PART
