| List of Spare Parts |
| Part No. |
Part Name |
| 2213412 |
SENSOR GROUP-PRESSURE (TRANSMISSION PUMP) |
| 1809340 |
SOCKET-CONNECTOR (14-GA TO 18-GA)(14-GA TO 18-GA) |
| 1552260 |
KIT-CONNECTING PLUG (3-PIN)(ENGINE SENSOR WIRING HARNESS) |
|
(INCLUDES PLUG AS & WEDGE) |
| 3243355 |
HARNESS AS-WIRING (XSMSN PUMP PRESSURE SENSOR) |
| 3243356 |
HARNESS AS-SOLENOID (XMSN PUMP BYPASS) |
| 1305300 |
CLIP (TAB) |
| 1325789 |
CLIP (LADDER) |
| 1488309 |
ADAPTER AS |
| 2P8421 |
ADAPTER (1-1/16-12) |
| 3D2824 |
O-RING - FOR OIL DRAIN & LEVEL PLUG (ITEMS 3 & 7) |
| 3J1907 |
SEAL VALVE ASSEMBLY TO SEAL- TUBE ASSEMBLY TO LOGIC VALVE |
| 4P7581 |
CLIP (FOR USE WITH 7.9MM WIDE TIE WRAP) |
| 4P8134 |
CLIP-LADDER (00800 MM ) |
| 7K1181 |
STRAP-PRESSURE & RETURN HOSES TO |
| 8T4121 |
WASHER-HARD (11X21X2.5-MM THK)(M10X1.50X30MM) |
| 8T4137 |
BOLT (M10X1.50X20MM) |
|
METRIC PART |
![[3359447-WIRING GROUP-FAN -COLD START]](https://crm.partsconexion.co/storage/Catalogue/Caterpillar/133/487/part_5133487.gif)
