| List of Spare Parts |
| Part No. |
Part Name |
| 6T6329 |
BEZEL-ROCKER SWITCH |
| 6V8927 |
BOLT-SOCKET HEAD (6-32X0.5IN) (6-32X0.5-IN) |
| 1564449 |
CABLE AS (HEATER TEMPERATURE CONTROL) |
| 1187259 |
GASKET (AIR CONDITIONER) |
| 1440900 |
SWITCH AS-ROCKER (VIBRATORY SELECT ON/OFF) |
| 3L8187 |
LOCKWASHER 7.24MM(.285IN.)O.D. (3.7X7.24X.48MM THK) |
| 6V8374 |
SCREW-MACHINE (6-32X0.25IN) (6-32X0.25-IN) |
| 1566821 |
AIR CONDITIONER GROUP |
| 7X0579 |
WASHER-HARD (8.8X25.5X2-MM THK) |
| 5A3604 |
BOLT-SOCKET HEAD (M8X1.25X25-MM) |
| 5P5643 |
SEAL 3.74 m(147.04 in.) |
| 1106109 |
KNOB-CONTROL |
| 9X8117 |
TUBE ASSEM. |
|
USE AS REQUIRED |
|
ORDER BY THE METER |
|
METRIC PART |
|
SEPARATE ILLUSTRATION |
![[1599405-SUPPORT GROUP-VIBRATORY -DRUM]](https://crm.partsconexion.co/storage/Catalogue/Caterpillar/262/202/part_8262202.gif)
