1951345-CONTROL GROUP-AUTO START/STOP

1951345-CONTROL GROUP-AUTO START/STOP

Brand	Caterpillar
Model	TH31-C9I
Part Number	1951345
Description

List of Spare Parts
Part No.	Part Name
9W1494	KIT-SERVICE METER (INCLUDES FILM)
	(INCLUDES SERVICE METER AND SERVICE FILM)
1111325	BLOCK-CONTACT (2-POLE)
1096507	SWITCH-OPERATOR (SECONDARY STOP PUSH BUTTON)
3E0156	SWITCH GROUP-START (IGNITION)
6V8362	SCREW-MACHINE (8-32X0.31-IN)
7T6799	NUT-MOUNTING (1-32-THD)
9B7233	LOCKWASHER (INT'L TOOTH)
2N2371	LAMP AS-INDICATOR (RED)
2V7088	LENS-RED (WARNING, MAINTENANCE LAMP)
6V8367	LOCKWASHER (18.19X29.16X1.17MM THK)
6V8382	NUT-HEX (11/16-27 THD)
6V8817	SCREW-MACHINE (4-36X4.76-IN)
6T3643	CIRCUIT BREAKER AS (15-AMPERE)(ENGINE STARTING)
	(EACH INCLUDES)
6V8376	SCREW (MACHINE) (8-32X0.25 IN)
1251302	SWITCH GROUP-MAGNETIC -STARTING MOTOR, START RELAY
1951344	HARNESS AS-WIRING (AUTO START/STOP CONTROL)
1028805	KIT-RECEPTACLE (6-PIN)(DISPLAY MONITOR HARNESS)
	(INCLUDES RECEPTACLE AS AND WEDGE)
1275486	RECEPTACLE AS-CONNECTOR (1-PIN)
1552270	KIT-CONNECTING PLUG (2-PIN)(ENGINE SENSOR WIRING HARNESS)
	(INCLUDES PLUG AS AND WEDGE)
3K9520	GROMMET
8T4205	WASHER, FLAT-THIN(1/4) w/o Freespool Qty is 12
6V8185	NUT-FULL (1/4-20 THD) (1/4-20-THD)(FULL)
4M5281	CAPSCREW (HEX HD 1/4-20X3/4) (USE W/SPACER 2)
1107884	SWITCH AS-TOGGLE (MOMENTARY)(MANUAL ENGINE SPEED CONTROL)
3L8187	LOCKWASHER 7.24MM(.285IN.)O.D. (3.7X7.24X.48MM THK)
6T3631	NUT-HEXAGON-(15/32-32 THD)
6T3632	LOCKWASHER 15.08MM(.59IN.)O.D.
6T3633	LOCK RING (12.3MM ID)
6V8374	SCREW-MACHINE (6-32X0.25IN) (6-32X0.25-IN)
1372133	PLATE
1372113	ENCLOSURE
5P8500	KEY Total 2 pieces per unit (LITERATURE COMPARTMENT)
1375135	BRACKET
9F8125	LOCKWASHER-EXTERNAL TOOTH (NO.10)
4B1237	SCREW-MACHINE (10-32X12.7-MM)
3E8035	SCREW-MACHINE
7N5876	LAMP (24-VOLT, 0.2-AMPERE)(PANEL)
1419228	LAMP AS (INDICATOR)
2V7087	LENS-AMBER (DIAGNOSTIC LAMP)
1422245	FILM-CONTROL PANEL
	SEPARATE ILLUSTRATION
