7S2983-PUMP GROUP-TMSN & SCAVENGE

List of Spare Parts
Part No.	Part Name
1S5632	BODY AS-OIL PUMP
8M8489	DOWEL 15 mm(.59 in.) long
1S6457	BODY AS-OIL PUMP
7S2981	MANIFOLD AS-PUMP
9M0669	DOWEL (9.368MM DIA)
5M3320	BEARING-SLEEVE (1.25X1.38X1.25-IN)
8S3442	GEAR AS-PUMP (12-TEETH)(DRIVE)
8S3443	GEAR AS-PUMP (12-TEETH)(IDLER)
8S9169	MANIFOLD AS-PUMP
1M3909	BEARING-SLEEVE
1D4706	BOLT (3/8-16X6-IN)(LOCATIONS Y)
5F4899	BOLT-HEAD ASSEMBLY TO CYLINDER BLOCK
3S0004	WASHER (0.406X0.728X0.09-IN THK)
8M5007	SEAL 139.3 mm(5.484 in.) Diameter
8S6237	GEAR (12 Teeth)
5M7908	PLUG ASSEM.
3J1907	SEAL VALVE ASSEMBLY TO SEAL- TUBE ASSEMBLY TO LOGIC VALVE
3S4327	COVER-OIL PUMP
1B8736	KEY-WOODRUFF
9S1018	WASHER (9.73X19.05X0.84-MM THK)
9S4182	PLUG-O-RING (STRAIGHT THREAD O-RING)
3J7354	PACKING,PREFORMED PART OF KIT P/N 5R1427
